ODAKE CT7011 RTV Silicone Adhesive Sealant is a high-performance, room-temperature vulcanizing (RTV) silicone encapsulant specially formulated for the encapsulation and protection of LED soft strips and decorative LED lighting. This RTV silicone sealant provides superior sealing, waterproofing, and environmental protection, ensuring enhanced durability and reliable performance of LED components across diverse conditions.
Ideal for use in LED lighting assembly, ODAKE CT7011 helps extend the lifespan of LED products by safeguarding them against moisture, dust, and mechanical stress.
Excellent Waterproof Performance
Efficient Heat Dissipation
High Light Transmission
UV Resistance
Quick Curing & Easy Application
A glue 20kg/barrel
B glue 2kg/barrel
Store sealed below 25°C away from light. The shelf life is 6 months if unopened.
ODAKE CT7011 RTV Silicone Adhesive Sealant is primarily used for the encapsulation of LED lights, ensuring both sealing and heat management. Its versatility makes it ideal for use in a wide range of applications:
LED Soft Strip Encapsulation
mid-crystal or solar cell modules.
Circuit Board Coating
Extensively used in gifts, LED lighting, handicrafts, electronics, toys, and many other industries.
| Product Model | CT7011 | ||
| Glue A | Glue B | ||
| Before curing | Appearance: (transparent after mixing and curing) | Transparent | |
| Viscosity (25℃) mPa·s | 1090±100 | 53±5 | |
After curing | Hardness (25℃) Shore A | 24±2 | |
| Elongation at break (%) | — | ||
| Tensile strength (Mpa) | ≥0.8 | ||
| Thermal conductivity (W/m.k) | ≤0.5 | ||
| Volume resistivity (TΩ·m) | 1×1013 | ||
| Breakdown strength (kv/mm) | 23 | ||
Disclaimer
The data provided in this document are representative values derived from actual measurements and routine testing. Hexu Xinwang assumes no responsibility for data obtained through unauthorized personnel or testing methods not approved by the company. Due to variations in application conditions, the above information should be adapted to the user’s specific circumstances. Hexu Xinwang accepts no liability for individual cases, including, but not limited to, any loss of profits.
